Machines For The Aluminium Scaffolding.

Ladders Technology (Zhejiang) Co., Ltd. had developed the new machines for the aluminium scaffoldings.

With the seven work station arc punching machine, it can punch 7 pcs of the pipes.

the technical data of the Arc Punching machine:

Work Station: 7 Work Station

Feeding: Manual feeding the materials

Control: PLC+Screen

System Pressure: 14Mpa

Tons: 2.5T

Motor power: 7.5Kw

Voltage Input: 415V/50HZ

Power Output: 24V

Punching Size: 600-2000mm

Antiwear hydraulic oil: Summer（46#）Winter（32#）

Dimensions: 3080*2050*1250mm

Net Weight: 1400KGS
